Motorbike Battery Pack
A motorbike battery pack is an integral component of an electric motorcycle, around which the essence of the motorcycle's performance and efficiency revolves. This pack consists of multiple battery cells that collectively serve as the motorcycle's power source. However, it's more than just a simple energy container-it's a sophisticated system designed to enhance overall riding experience and environmental sustainability.
|
Electrical Characteristics |
Nominal Voltage |
60V |
|
Nominal capacity |
25Ah |
|
|
Energy |
1500Wh |
|
|
Internal Resistance |
≤15mΩ |
|
|
Cycle life |
≥4000 cycles @1C 100%DOD |
|
|
Months Self Discharge |
<3% |
|
|
Efficiency of Charge |
100% @0.5C |
|
|
Efficiency of Discharge |
96~99% @1C |
|
|
Standard Charge |
Charge Voltage |
14.6±0.2V |
|
Charge Mode |
0.2C to 14.6V, then 14.6V,charge current to 0.02C (CC/CV) |
|
|
Charger Current |
10A |
|
|
Max. Charge Current |
10A (depends on BMS) |
|
|
Charge Cut-off voltage |
14.6V±0.2V |
|
|
Standard Discharge |
Max Continuous discharge Current |
50A(depends on BMS) |
|
Max. Pulse Current |
depends on BMS |
|
|
Environmental |
Charge Temperature |
0 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity |
|
Discharge Temperature |
-20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity |
|
|
Storage Temperature |
0℃ to 40 ℃ (32F to 104F) @60±25% Relative Humidity |
|
|
Water Dust Resistance |
IP65 |
|
|
Mechanical |
Cell & Method |
14S12P |
|
Plastic Case |
ABS |
|
|
Dimensions (mm) |
Can be customiszed |
|
|
Weight |
35KG |
|
|
Terminal |
M8 |
Product Detail
Our Production Line
Our Certifications
High-quality motorbike battery packs are designed to optimize energy storage, granting motorcycles an extended range. The energy density of these batteries plays a fundamental role in determining the distance a motorbike can travel without needing a recharge. These packs also directly impact the vehicle's speed and acceleration, both crucial elements for sporty and adventurous riders.
