Lithium Ion Battery For Electric Scooter
Lithium-ion batteries have become the preferred power source for electric scooters due to their many advantages. Not only do they offer superior performance qualities, but they also have exceptional longevity, making them a reliable and cost-effective choice.
Known for their high energy density, lithium-ion batteries allow electric scooters to achieve longer travel ranges on a single charge. This makes them incredibly efficient and practical for daily use, whether for commuting, errands, or leisure rides. Their lightweight nature also enhances the scooter's overall ease of maneuverability and speed, without adding unnecessary weight.
|
Electrical Characteristics |
Nominal Voltage |
36V |
|
Nominal capacity |
50Ah |
|
|
Energy |
1800Wh |
|
|
Internal Resistance |
≤15mΩ |
|
|
Cycle life |
≥4000 cycles @1C 100%DOD |
|
|
Months Self Discharge |
<3% |
|
|
Efficiency of Charge |
100% @0.5C |
|
|
Efficiency of Discharge |
96~99% @1C |
|
|
Standard Charge |
Charge Voltage |
14.6±0.2V |
|
Charge Mode |
0.2C to 14.6V, then 14.6V,charge current to 0.02C (CC/CV) |
|
|
Charger Current |
10A |
|
|
Max. Charge Current |
10A (depends on BMS) |
|
|
Charge Cut-off voltage |
14.6V±0.2V |
|
|
Standard Discharge |
Max Continuous discharge Current |
50A(depends on BMS) |
|
Max. Pulse Current |
depends on BMS |
|
|
Environmental |
Charge Temperature |
0 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity |
|
Discharge Temperature |
-20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity |
|
|
Storage Temperature |
0℃ to 40 ℃ (32F to 104F) @60±25% Relative Humidity |
|
|
Water Dust Resistance |
IP65 |
|
|
Mechanical |
Cell & Method |
13S10P |
|
Plastic Case |
ABS |
|
|
Dimensions (mm) |
Can be customiszed |
|
|
Weight |
35KG |
|
|
Terminal |
M8 |
Product Detail
Our Production Line
Our Certifications
High energy density is another admirable advantage of lithium scooter batteries. It provides the scooter with the ability to cover longer distances on a single charge. This makes electric scooters equipped with lithium batteries an excellent choice for commuting, particularly over longer distances.
