Tigershark 36V 10Ah Lithium Ion Battery Pack for Electric Bike

Tigershark 36V 10Ah Lithium Ion Battery Pack for Electric Bike

Tigershark 36v 10Ah lithium ion battery pack for electric bike Product detail Package and shipping Production time Sample order 5-7 days. Bulk order 7-15 days. Warranty terms If a few batteries are defective, we only need clients to provide bar code.Then we will add the replacement on the next...

Description

Tigershark 36v 10Ah lithium ion battery pack for electric bike

Tigershark battery is made to replace downtube battery.Maybe downtube battery(dolphin)has shortage,or lasts too long time.Tigershark is going to cover all its shortage.

Still same mounting way,fitted on the 45 degree frame,the case looks like a shark openning the mouth.

Specification

Nominal Voltage

36V

Nominal Capacity(0.5C,25℃)

10Ah

Weight(Approximate)

≤4.3kg

Dimension(Length*Width*Height)

340*130*80mm

Standard Discharge

Max. Continuous Current

20A

Over Current

50A

Cut-off Voltage

30V±1V

Standard Charge

Charge Voltage

42.0V±0.2V

Recommended Charge Current

2A

Charge Time

5-5.5hours

Resistance and rates

Internal Resistance

≤110mΩ

Self-discharge rate

≤4% per Month

General Features

Assembly cell

10S4P-18650 -2550mAh (3C)

BMS discharge protection

20A-50A

Battery cycle life

900    times(DOD 80%)

Product detail





FAQ

37. Do we do EXW term?

No, we do not accept, because your local forwarder will not pick goods from our factory, so to prevent this issure, we stop to do EXW term.



38. Do we supply spare parts?

Yes, for VIP clients we will give BMS or cells for free spare parts. We also sell chargers and BMS.If client needs controller or motor, we will help to purchase.



39. Do we make other battery packs in other industry?

Yes, we do battery for e-mobility, LED, solar power and tools industries.

We also have prismatic cell source, so big motive battery or storage battery are ready to manufacture.
